Characters of DTG printer:
Stable Quality:
1.Original technology by ourselves
2.Best Imported white ink,not clogging printhead
3.Automatic white ink circulation and bubble filter to avoid sediment
Fast Speed:
1.Print 10pcs automatically
2.two Epson5113 printheads (each head with 4 priting lines)
3.Print white and CMYK at the same time
4.Bi-direction; "Normal" and "fast" speed to choose
5.white T-shirt 1min/pc by4 pass(720x2400dpi), dark T-shirt 2min/pc by 4 pass, dark T-shirt3min/pc by 6 pass(720x3600dpi).
Excellent Details:
1. 4 different printing tables
2.Bowl screws to control moving
3.English manual pannel
4..Strong underbed
Printing tables
1.250*300mm
2.350*400mm
3.400*500mm
4.450*600mm
| Model: | GB-4060 |
| Max print size: | 420 mm * 900mm; capable for three pcs of t-shirts |
| Photo quality: | 2880 * 2880dpi |
| Ink type: | Pigment ink for T-shirt direct printing |
| ink channel: | CMYK WWWW/ Double CMYK |
| Printing interface: | USB 2.0 & 100 Base-T Ethernet interface |
| Printing Direction: | Bi-directional Printing Mode |
| Printing speed: |
white T-shirt 40s/pc by 3 pass white T-shirt 60s/pc by 4 pass white T-shirt 90s/pc by 6 pass dark T-shirt 90s/pc by 3 pass dark T-shirt 120s/pc by 4 pass dark T-shirt 180s/pc by 6 pass |
| Printing method: | micro piezoelectric printing technology; intelligent nozzle clogging sensor system |
| Production capacity: | 500 pcs t-shirts/ 8 working hours |
| Normal working environment: | Temperature 10 °C ~ 35 °C; Humidity 20 ~ 80 RH |
| Machine configuration: | USB line; driving software; power line; instruction book; washing and ink-joiner tools |
